DEVA Broadcast DB3010 IP Radio Monitor

DEVA Broadcast DB3010 IP Radio Monitor

With an ever increasing proportion of audiences tuning to station’s online streams it’s becoming more important to monitor them for faults. DEVA Broadcast’s new DB3010 allows the monitoring of both FM and web streams from one box, winning both Radio World and Radio Magazine ‘Best of Show’ awards at NAB 2015.

Now you can know if your station’s web stream is down before someone alerts you – the DB3010 will send an automatic email and SNMP trap and log the fault. Front panel indicators show a quick visual indication of audio levels and RF signal, and soft keys allow quick switching between 4 preset stations. Impressive front panel speakers with active crossovers and a dedicated bass reflex speaker produce powerful sound from the 1U device.

DB3010-confidence-monitor-front

The DB3010 also measures and logs received RF level, MPX deviation, L/R audio levels for later analysis. Analog and digital outputs can be used for local monitoring or distributing the received audio to other destinations.

DB3010-confidence-monitor-back

 DB3010 Feature List

  • Advanced Internet Radio Monitoring Capabilities
  • Automatically decodes AAC, AAC+, MP3 and PCM IP audio
  • Supports all standard bitrates and VBR encoding
  • SHOUTcast / ICEcast compatible
  • Automatically displays live metadata for all standards
  • Adjustable alarms for stream loss and Internet connection loss
  • DSP controlled, high efficient class-D switching amplifier
  • Accurate 3-way speaker system with 2 mid/high frequency speakers for excellent stereo imaging
  • Active crossover for perfect separation between mid-range and bass bands
  • Magnetically shielded drivers that allow placement next to video monitors
  • SNTP for automatic synchronization of the built-in clock
  • Balanced analog and AES/EBU audio outputs on XLR connectors
  • LAN port for full TCP/IP remote control and monitoring
  • Adjustable MIN/MAX alarms for RF, L/R audio levels
  • Alarm dispatch via E-mail, SNMP ver.2C and GPO
